Technical Data
|
Test Items |
Test Meth |
od |
Test Value |
|
|
Fire Hazard Classification |
ASTM E8 UL 723 |
4 |
Flame Spread <25 Smoke Developed <50 Grade A incombustible materials≤0.3 |
|
|
Thermal Conductivity |
ASTM C518 |
0.034 - 0.048 (W/m·K) |
||
|
Corrosion Resistance |
ASTM C6 |
65 |
Will not accelerate corrosion of steel or copper. |
|
|
Resistance To Fungi And Bacteria |
ASTM C6 |
65 |
Does not breed or promote fungi or bacteria growth. |
|
|
Moisture Absorption |
ASTM C 1 GB 5480.7 |
104 -87 |
3% of weight(49，relative humidity Moisture absorption 90%) 5% of weight(49，relative humidity90%) |
|
|
Moisture Permeability |
ASTM E96 GB/T 17146-1997 |
Max.0.013g/24h·m2·mercury/mm |
||
|
Temperature Range |
ASTM C411 |
Up to 4 |
00 °C |
|
| Test Items | TestMethod | Test Value |
| FireHazard Classification | ASTM E84 UL723 |
Flame Spread<25 Smoke Developed<50 GradeAincombustible materials≤0.3 |
| Thermal Conductivity | ASTMC518 | 0.034-0.048(W/m ·K) |
| Corrosion Resistance | ASTM C665 | Will not accelerate corrosion ofsteel orcopper. |
| ResistanceTo FungiAndBacteria | ASTM C665 | Doesnot breedor promote fungior bacteriagrowth. |
| Moisture Absorption | ASTMC1104 GB5480.7-87 |
3%of weight(49,relativehumidity Moisture absorption 90%) 5%of weight(49,relative humidity90%) |
| Moisture Permeability | ASTM E96 GB/T17146-1997 |
Max.0.013g/24h ·m2 ·mercury/mm |
| Temperature Range | ASTM C411 | Upto 400°℃ |
|
R-value |
Nominal Width [mm] |
Length [mm] |
Density [kg/m³] |
Thickness [mm] |
|
Wall Segments |
|
|
|
|
|
R1.5 |
75 |
430 or 580 |
1160 |
8.1 |
|
R2.0 |
75 |
430 or 450 or 580 or 600 |
1160 |
17.3 |
|
R2.0 |
90 |
430 or 580 |
1160 |
9.4 |
|
R2.5 |
90 |
430 or 580 |
1160 |
20.1 |
|
R2.7 |
90 |
430 or 580 |
1160 |
28.2 |
|
R4.0 |
140 |
430 or 580 |
1160 |
22.5 |
|
Celing Segments |
|
|
|
|
|
R3.0 |
145 |
430 or 580 |
1160 |
7.9 |
|
R3.5 |
175 |
430 or 580 |
1160 |
7.4 |
|
R4.0 |
195 |
430 or 580 |
1160 |
7.8 |
|
R5.0 |
210 |
430 or 580 |
1160 |
11.4 |
|
R6.0 |
275 |
430 or 580 |
1160 |
9.0 |
|
Multi Use Rolls |
|
|
|
|
|
R2.0 |
90 |
430 or 580 |
19000 |
9.4 |
|
Insulation -Roof Blanket |
|
|
|
|
|
R1.3 |
55 |
1200 |
30000 |
12.0 |
|
R1.8 |
75 |
1200 |
23000 |
11.7 |
|
R2.3 |
100 |
1200 |
17500 |
10.4 |
|
R2.5 |
105 |
1200 |
16500 |
11.4 |
|
R3.0 |
120 |
1200 |
14500 |
13.4 |
|
R3.6 |
145 |
1200 |
10000 |
13.0 |
|
Space Blanket |
|
|
|
|
|
R1.3 |
55 |
1200 |
15000 |
12.0 |
|
R1.8 |
75 |
1200 |
10000 |
11.7 |
Application
Glass wool insulation materials according to different application scenarios, developed a higher adaptability of a variety of products. The unique product design makes the working condition temperature reach 442 °C,which is widely used in the industrial equipment and the piping insulation engineering with the hot surface temperature height of 25o C, can meet the petroleum, chemical, light industry, metallurgy and other industries and power plant flue,hot air duct,dust catcher, chimney lining, deaerator tank, pulverizing system, desulphurization equipment heat insulation requirements, also suitable for pipe diameter greater than 2oomm of various processes, long heat transfer network pipeline insulation.
The Field of Petrochemical Industry
Steel Construction
Commercial Construction
Electromechanical Heating and Ventilating System
Smoke Control and Exhaust System for Industrial Buildings
The Field of Energy and Electricity
